Gleason model Phoenix 125GH 6-Axis CNC vertical Gear Hobber, W/ Optional 8" Diameter software parameters !!!

Gleason Phoenix Vertical 6-Axis CNC Gear hobber
Model 125GH / 200 (Extended option available)
s/n 912615
delivered 10/1995

This Gleason Model 125GH machine parameters can be extended to
accomodate 8" diameter parts . the machine parameters and software
can be upgraded and installed by Gleason corp. The machine also
has the optional 20 HP heavy duty spindle motor.

machine specifications are as follows:
Max workpiece diameter 5" / 125 mm standard
Max workpiece diameter 8" / 207 mm optional*
Min workpiece Diameter .25" / 6.4 mm
Max Pitch / Module 8 NDP/ 3.2 Module
Max Axial slide travel 11.81"/ 300 mm
Max Hob Head Swivel -180 -+ 40 degrees
Max diameter Hob 4.53" / 115 mm
Max Hob length 8.46" / 215 mm
Max hob Shifting length 7.87" / 200 mm
Max work head speed 1500 rpm
Max work head speed (optional) 3500 rpm
Hob Head drive rating 20 HP *
Machine weight 15,000 lbs
floor space 106" x 65" x 122" high

Machine is equipped with the following:
GE Fanuc 15-M cnc controls
180 position loader with loading station
20 HP optional spindle motor
Extended software parameters bty gleason Additional 25k options inquire
light curtains
Chip conveyor
Mist collection
books and manuals

Machines can be inspected in our warehouse under power with proper
notice. Machines will be loading out shortly as we have just purchased these
. Contact us today as these machines were upfit by gleason w/ new software
and are in good running condition or Visit WWW.PiselliEnt.com to view more
photos of this machine offering or others we have in stock!! email Rich
Piselli at Rich@pisellient.com for more information.
