Barber colman model 16-56 type A gear hobber , 16" diameter 56" cut length w/ 66" shaft length, w/ Downfeed, single thread worm , s/n 2816
Barber Colman horizontal hobber
Model 16-56
s/n 2816
Machine is equipped with Downfeed
Suitable for the cutting of spur gears, pinions, splines, and
other work pieces of similar profile up to 16"pitch diameter
and 56" face width.
PRINCIPLE SPECIFICATIONS:
Maximum rated work dia 16"
Coarsest pitch, one cut in steel 6 D.P.
Work spindle bore 3 1/8"
Maximum travel of hob carriage 56"
Max distance from face plate to center 66"
Maximum dist work spindle face to C.L. of hob spindle
Min. 3 1/2"
max. 59 1/2"
C.L. work spindle to C.L. of hob spindle
Min. 1/2"
max. 8 1/2"
Maximum hob dia. 5"
Hob Speed 425 RPM
Feed ranges .015 to .150 i.p.r.
Maximum swivel angle setting, L or R 45 degrees
Approximate floor space 122" x 38"
Approximate height 76"
Approximate net weight 10,000 LBS.
EQUIPMENT FEATURES:
- Automatic Lubricating System
- Assortment of Change Gears
- Standard Hob Slide W/Swivel Hob-Head ( /- 45 Degrees Swivel)
- Downfeed mechanism
- 3 1/8" Bore through work spindle
- Standard Over Arm Support W/Adjustable Lever-Type Tailstock W/Center
- One (1) Hob Arbor 1-1/4"
- Single start Thread Index Worm
- Power Rapid Traverse For Hob Carriage
- Complete Coolant System, Pump Tank & Piping
- Full Complement Of Electrics (Motors/Controls)
Machine can be inspected in our statesville plant under power.
