Gleason Model CG 300 CNC cutter sharpener for both style blades blades , robotic loading as well s/n 925801
Gleason CNC cutter Blade Sharpening Machine
Model CG 300
s/n 925801
NEW TBD
with integrated Robot loading
this 5-axis machine was designed to sharpen the Gleason style blades
for their Bevel cutting machines for RSR, TRI-AC & PENTAC styles
as well as other profiles in other industries!
Machine specifications as follows
Control Unit Siemens
X axis - working head base 305 mm
Y axis - grinding wheelbase 305 mm
Z axis - grinding wheel head 305 mm
Axis speed (X, Y, Z) 85 mm / s
Wheel diameter 304.8 mm
Spindle power 7.3 kW
Ø grinding wheel 304.80 mm
Spindle speed 2000 - 3000 rpm
Dimensions L 2200 x W 3560 x H 2200 mm
Weight approx. 8000 Kg
machine is equipped with the following :
Siemens controls
Integrated robot and loading station for loading
fully enclosed working area
full hydraulic and chilling system
filtration unit
wheel flange and wheel set up for blade sharpening
manuals and books
note: full specifications upon request !!
this machine can be inspected in our Statesville NC warehouse with
proper notice , the machine was delivered from customers location
due to scaling back operations of its bevel Department. visit our
website at WWW.Pisellient.com for more information and photos.
Request a formal quote on line with pricing or contact Rich Piselli
at rich@pisellient.com to set up an inspection !!
