Gould & Eberhardt model 120 160/ 8000 EXT, 8 Meter Hobber Gasher , with several heads , excellent condition remanufactured in 2014

Gould & Eberhardt CNC Hobber / Gasher
Model 120-160/8000
remanufactured in 2014
in plant excellent condition

this machine was originally MFG by G&E in 1997. the machine was extended and
re-manufactured with new extended base and x-axis ballscrew and special heads
were purchased to handle the larger diameter gears . additional hydraulic
steadies were also added to assist in supporting all the additional weight with
cutting larger diameter gears . machine maintains quality 10 agma when gashing
large diameter gears

machine specifications are as follows:
max diameter capacity for external gashing 8 Meter
max diameter capacity for hobbing 5.5 meter
max face width spur gear 55" 1,410 mm
Max Face width Helical Gear depends on angle
Max head swivel +/- 45 degrees
max pitch .5 DP
main table diameter 2.61 meters
max table weight 80 tons
max diameter gashing cutter 24"
Max diameter hob 13.5"
machine weight 135,000 lbs

Machine is equipped with the following :
GE fanuc CNC 5 axis controls
External Hobbing & Gashing head
Heavy duty external gashing head for 8 Meter
Hydraulic outboard steadies for heavy table weights
chip conveyors
hydraulic chilling unit
pendant arm controls
full books and manuals
foundation drawings and plans
Note: internal gashing head can be purchased at additional cost !!

this machine can be inspected under power in excellent operating condition
machine can also be tested under power with purchase order and down payment
contact rich Piselli at rich@Pisellient.com for inspection or formal quote
with pricing . visit www.pisellient.com to also request a formal quote.
