Gould & Eberhardt model 24H , differential , infeed , 1/54, 10/N , good running machine from small aerospace shop with lots of tooling and gears, s/n 80266
Gould & Eberhardt vertical gear hobber
Model 24H
s/n 80266
Standard Hob head w/ Differential
This machine is Equipped with Differential and standard
head to handle cutting straight spur & Helical
gears. Its an Excellent job shop machine .
Machine corresponds to the following:
Coming out of a small aerospace gear shop in canada , special price
loaded on truck next week only 4/1/25 , after below price and terms
will apply !!!! call now if interested !!
MACHINE SPECIFICATIONS:
* Max. DP in Steel 3 DP
* Face Capacity 15"
* Max. Diam. Spur Gear W/Support 18"
* Max. Diam. Spur Gear W/out Support 24"
* Min. Centers Work and Hob Arbors 0"
* Max. Diam. Hob 6"
* Diameter Work Table 18"
* Diameter Index Worm Gear 18"
* Hob Speeds 40-240 RPM
* Feed Range .03-.200"
* Main Motor 7 1/2 HP.
* Floor Space Required x Height 67" X 142" X 88"
* Approximate Weight 12,000 LBS
MACHINE IS EQUIPPED WITH THE FOLLOWING:
* standard bevel Drive Hob Head
* Differential
* push button controls
* Tailstock swing away ( w/ tye-Bar)
* Hob arbor 1-1/4" dia
* 10/N with 54 teeth in worm wheel
* Misc Change gears and tooling
Machine can be inspected in our Statesville NC warehouse with proper
notice under power . visit our website at wwww.Pisellient.com to so our
vast inventory of gear machines . contact us today for more information
or contact rich directly at Rich@PiselliEnt.com
